Bewegungsplanung

Planen Sie mobile Roboterpfade mit RRT

Dieses Beispiel zeigt, wie der RRT-Algorithmus (Rapsful Exploring Random Tree) zum Planen eines Pfads für ein Fahrzeug durch eine bekannte Karte verwendet wird. Mit einem benutzerdefinierten Zustandsraum werden auch spezielle Fahrzeugseinschränkungen angewendet. Sie können Ihren eigenen Planer mit benutzerdefinierten Zustandsraum- und Pfadvalidierungsobjekten für jede Navigationsanwendung optimieren.

Dynamische Neuplanung auf einer Innenraumkarte

Dieses Beispiel zeigt, wie eine dynamische Neuplanung auf einer Lagerkarte mit einem Entfernungsmesser und einem A*-Pfadplaner durchgeführt wird.

Highway Lane Change

Perceive surround-view information and use it to design an automated lane change maneuver system for highway driving scenarios.

Motion Planning with RRT for Fixed-Wing UAV

Plan the 3D motion of a fixed-wing UAV using the rapidly exploring random tree (RRT) algorithm, given a start and goal pose.

(UAV Toolbox)

Highway Trajectory Planning Using Frenet Reference Path

Demonstrates how to plan a local trajectory in a highway driving scenario. This example uses a reference path and dynamic list of obstacles to generate alternative trajectories for an ego vehicle. The ego vehicle navigates through traffic defined in a provided driving scenario from a drivingScenario object. The vehicle alternates between adaptive cruise control, lane changing, and vehicle following maneuvers based on cost, feasibility, and collision-free motion.

Reverse-Capable Motion Planning for Tractor-Trailer Model Using plannerControlRRT

Find global path-planning solutions for systems with complex kinematics using the kinematics-based planner, plannerControlRRT. The example is organized into three primary sections:

Object Tracking and Motion Planning Using Frenet Reference Path

Dynamically replan the motion of an autonomous vehicle based on the estimate of the surrounding environment. You use a Frenet reference path and a joint probabilistic data association (JPDA) tracker to estimate and predict the motion of other vehicles on the highway. Compared to the Highway Trajectory Planning Using Frenet Reference Path example, you use these estimated trajectories from the multi-object tracker in this example instead of ground truth for motion planning.

Optimization Based Path Smoothing for Autonomous Vehicles

Optimize the path for a car-like robot by maintaining a smooth curvature and a safe distance from the obstacles in a parking lot.

Benchmark Path Planners for Differential Drive Robots in Warehouse Map

Choose the best 2-D path planner for a differential drive robot in a warehouse environment from the available path planners. Use the plannerBenchmark object to benchmark the path planners plannerRRT, plannerRRTStar, plannerBiRRT, plannerPRM, and plannerHybridAstar on the warehouse environment with the randomly chosen start and goal poses. Compare the path planners based on their ability to find a valid path, clearance from the obstacles, time taken to initialize a planner, time taken to find a path, length of the path, and smoothness of the path. A suitable planner is chosen based on the performance of each path planner on the above mentioned metrics.

Offroad Planning with Digital Elevation Models

Process and store 2.5-D information, and presents various techniques for using it for an offroad path planner.

Enable Vehicle Collision Checking for Path Planning Using Hybrid A*

Use a Hybrid A* planner to plan a path to a narrow parking space, while accounting for the shape of a car-like robot.

Plan Path to Custom Goal Region for Mobile Robot

Plan a path for a mobile robot to a goal region using a rapidly exploring random tree (RRT) path planner. In this example, you can define a custom goal region as a 2-D polygon, and then plan a path to it.

Hybrid Sampling Method for Motion Planning in Warehouse Environment

Combine uniform sampling and Gaussian sampling approaches for motion planning in narrow passages and wide spaces.

Plan Path in Warehouse Scenario with Unseen Obstacle Avoidance

Plan path in a warehouse scenario by avoiding unseen obstacles using TEB algorithm.

Train Deep Learning-Based Sampler for Motion Planning

Create a deep learning-based sampler using Motion Planning Networks to speed up path planning using sampling-based planners like RRT (rapidly-exploring random tree) and RRT*. For information about Motion Planning Networks (MPNet) for state space sampling, see Get Started with Motion Planning Networks.

Accelerate Motion Planning with Deep-Learning-Based Sampler

The example shows how to use sampling-based planners such as RRT (rapidly-exploring random tree) and RRT* with Motion Planning Networks (MPNet), deep-learning-based sampler to find optimal paths efficiently.

Route Planning in Uneven Terrain Based on Vehicle Requirements

Use navGraph and plannerAStar to find a path through rough terrain while accounting for vehicle-based requirements and constraints.

Path Planning Using MPNet for Automated Parking Valet System

Perform path planning for an automated parking valet system using a pretrained MPNet.

Simulate Path Following on Speedgoat Real-Time Target Machine

Perform real-time simulation of path following on Speedgoat real-time target machine.

Avoid Obstacles Using TEB Local Planner in Simulink

Perform path following using TEB local planner in Simulink.
