Modellreferenzen

Wiederverwendung von Modellen als Blöcke in anderen Modellen

Eine Modellreferenz ist eine Referenz auf ein anderes Modell mithilfe eines Model-Blocks. Diese Referenzen schaffen eine Modellhierarchie. Jedes referenzierte Modell hat eine definierte Schnittstelle, die die Eigenschaften seiner Eingaben und Ausgaben festlegt. Die definierte Schnittstelle macht das Verhalten des referenzierten Modells unabhängig von seinem Kontext in der Modellhierarchie. Modellreferenzen sind ideal für die Wiederverwendung von Code, Unit-Tests, parallele Builds und große Komponenten. Sie können auch Dateikonflikte reduzieren und Probleme zusammenführen.

Um festzustellen, ob referenzierte Modelle Ihre Modellierungs-Anforderungen erfüllen, siehe Component-Based Modeling Guidelines.

Informationen über die Codegenerierung für Modellreferenzhierarchien finden Sie unter Referenced Models (Simulink Coder).

Um ein geschütztes Modell zu erstellen, siehe Model Protection (Simulink Coder).

Wie Sie SIL/PIL-Tests für eine Modellreferenzhierarchie durchführen, erfahren Sie unter SIL and PIL Simulations (Embedded Coder).

Blöcke

Model	Reference another model to create model hierarchy
Variant Model	Template subsystem containing Subsystem blocks as variant choices

Funktionen

alle erweitern

Referenzierte Modelle

`depview`	Analyze and visualize model referencing dependencies with or without library dependencies
`find_mdlrefs`	Find referenced models and Model blocks in model hierarchy
`pathsToReferencedModel`	Model hierarchy path composed of referenced models and Model blocks (Seit R2023b)
`Simulink.BlockDiagram.refreshBlocks`	Update variants, linked blocks, and model references to reflect changes (Seit R2023a)
`Simulink.BlockPath`	Fully specified Simulink block path
`Simulink.fileGenControl`	Specify root folders for files generated by diagram updates and model builds
`Simulink.ModelReference.refresh`	Force update to Model block to reflect changes to referenced model (Seit R2020a)
`Simulink.SubSystem.convertToModelReference`	Convert subsystems to models
`slbuild`	Build standalone executable file or model reference target for model
`slxcinfo`	Query contents of Simulink cache files (Seit R2020b)
`slxcunpack`	Unpack simulation and code generation targets from Simulink cache file (Seit R2020b)

Geschützte Modelle

`Simulink.ProtectedModel.createHarness`	Create harness model that provides isolated environment for testing protected model (Seit R2020b)
`Simulink.ProtectedModel.getPublisher`	Return information about publisher that signed the protected model (Seit R2020a)
`Simulink.ProtectedModel.verifySignature`	Verify digital signature on protected model (Seit R2020a)
`Simulink.ProtectedModel.suppressSignatureVerification`	Suppress digital signature verification of protected models (Seit R2020b)

Modelleinstellungen

alle erweitern

Modellreferenzierung

Rebuild	Option to conditionally, always, or never rebuild model reference targets
Niemals Rebuild-Diagnostik	Diagnostic action to take when model reference target must be rebuilt
Parallele Modellreferenz-Builds aktivieren	Option to build a model reference hierarchy in parallel whenever possible
MATLAB Worker-Initialisierung für Builds	Options for how to initialize MATLAB workers for parallel builds
Strenge Scheduling-Prüfungen für referenzierte Modelle aktivieren	Option to check consistency of scheduling and sample time in referenced models
Gesamtzahl der erlaubten Instanzen pro Top-Modell	Number of references to this model that can occur in another model
Propagieren von Signalen variabler Größe	Option to specify how variable-size signals propagate through referenced models
Minimierung des Auftretens algebraischer Schleifen	Option to try to eliminate artificial algebraic loops related to referenced model
Weitergabe aller Signalbeschriftungen aus dem Modell	Option to pass propagated signal names out of referenced model
Lokalen Solver verwenden bei Referenzierung eines Modells	Option to use local solver to solve referenced model as separate system of equations (Seit R2022a)
Modell-Abhängigkeiten	User-created files and data that potentially impact simulation results
Konsistenzprüfung im parallelen Pool durchführen	Option to perform checks on parallel pool before starting parallel build (Seit R2021a)
Benutzerdefinierten Code für referenzierte Modelle einbeziehen	Option to use custom code in model reference simulation target
Übergabe skalarer Wurzeleingaben fester Größe nach Wert für die Codegenerierung	Option to pass scalar input to model by reference or value

Modellreferenzierungs-Diagnostik

Nicht übereinstimmende Modell-Blockversion	Diagnostic action to take when Model block does not represent current version of referenced model
Nicht übereinstimmende Ports und Parameter	Diagnostic action to take when port or parameter does not match between Model block and referenced model
Nicht unterstützte Datenprotokollierung	Diagnostic action to take when data logging is unsupported
Kein expliziter Endwert für Modell-Argumente	Diagnostic action to take for model argument with default value at top-level model reference (Seit R2020b)
Unzureichende Identifikator-Höchstlänge	Diagnostic action to take when maximum identifier length is too short to ensure unique global identifiers

Tools

Model Reference Conversion Advisor	Convert subsystems to referenced models
Fensterbereich "Referenced Files"	View, save, and close referenced subsystems and models (Seit R2020b)

Themen

Festlegung, wann Modelle referenziert werden

Component-Based Modeling Guidelines
Consider componentization for large models and multiuser development teams.
Model Reference Basics
Decide whether to reference one model in another model.
Model Reference Requirements and Limitations
Model references have requirements and limitations relating to features such as reusability, simulation modes, masking, and debugging.

Erstellung von Modellreferenzen

Reference Existing Models
Include a model in another model.
Reference Protected Models from Third Parties
Use a protected model that you received from a third party.
Convert Subsystems to Referenced Models
Prepare a subsystem for conversion, convert the subsystem to a model, and compare simulation results before and after conversion.
Define Model Reference Interfaces
Ports in the referenced model correspond with ports at the model reference. Signals that cross the model boundary must meet certain requirements.
Inspect Model Hierarchies
Examine the contents, structure, model versions, and logged signals in a model hierarchy.

Konfiguration von Modellreferenzen

Set Configuration Parameters for Model Hierarchies
Configuration parameter values can be different in top models and referenced models. Some configuration parameter values have special requirements or behavior with model referencing.
Conditionally Execute Referenced Models
Execute referenced models conditionally, similar to conditionally executed subsystems.
Referenced Model Sample Times
A referenced model can inherit sample times from the model that references it.
Configure Instance-Specific Values for Block Parameters in a Referenced Model
When you model a reusable component as a referenced model, to configure each instance of the component to use different values for block parameters, create model arguments.
Parameterize a Referenced Model Programmatically
This example shows how to programmatically configure multiple instances of a referenced model to use different values for the same block parameter.
Group Multiple Model Arguments into a Single Structure
This example shows how to programmatically configure multiple instances of a referenced model to use different values for the same block parameter by using structures.
Configure Instance-Specific Data for Lookup Tables Programmatically
When you use Simulink.LookupTable objects to store and configure lookup table data for ASAP2 or AUTOSAR code generation (for example, STD_AXIS or CURVE), you can configure the objects as model arguments.

Simulation von Modellhierarchien

Choose Simulation Modes for Model Hierarchies
Select the simulation mode for models in a model hierarchy.
Manage Simulation Targets for Referenced Models
A simulation target, or SIM target, is a MEX-file that implements a referenced model that executes in accelerator mode.
Share Simulink Cache Files for Faster Simulation
Use Simulink cache files to share build artifacts that let you avoid the cost of a first-time build.
Override Model Reference Simulation Modes
When a top model simulates in normal mode, you can override the simulation mode used for model references without dirtying their parent models.
Reduce Update Time for Referenced Models by Using Parallel Builds
Reduce diagram update time for large model reference hierarchies by using parallel builds.
Simulate Conditionally Executed Referenced Models
Run a standalone simulation of a conditionally executed referenced model.
Simulate Multiple Referenced Model Instances in Normal Mode
Simulate a model that contains multiple instances of a referenced model.

Enthaltene Beispiele

Component-Based Modeling with Model Reference

Walks you through simulation and code generation of a model that references another model multiple times.

Live Script öffnen

Visualize Model Reference Hierarchies

View, explore, and analyze model dependencies using the Dependency Analyzer.

Beispiel öffnen

Convert Subsystem to Referenced Model

Convert a subsystem to a referenced model by using the Model Reference Conversion Advisor or the Simulink.SubSystem.convertToModelReference function.
