Transmit and Capture

Transmit and capture IQ data over the air for use in simulation, testing, and validation

Configure your software-defined radio (SDR) as a high-speed baseband transmitter, baseband receiver, or baseband transceiver for transmitting or capturing IQ data over the air. Use the captured data to analyze, simulate, test, and validate wireless systems.

Objects

basebandReceiverConfigure SDR as baseband receiver (Since R2022a)
basebandTransceiverConfigure SDR as baseband transceiver (Since R2022a)
basebandTransmitterConfigure SDR as baseband transmitter (Since R2022a)

Functions

captureCapture IQ data using baseband receiver or transceiver (Since R2022a)
isCapturingStatus of capture running in background using baseband receiver (Since R2024a)
captureOutputsRetrieve outputs from capture run in background using baseband receiver (Since R2024a)
stopCaptureStop capture running in background using baseband receiver (Since R2024a)
transmitTransmit waveform using baseband transmitter or transceiver (Since R2022a)
stopTransmissionStop transmission from baseband transmitter or transceiver (Since R2022a)

Apps

Wireless Waveform GeneratorCreate, impair, visualize, and export modulated waveforms

Featured Examples
