AXI4 Random Access Memory
Model random access through external memory
- Library:
SoC Blockset / Memory
Description
The AXI4 Random Access Memory block models a connection between two hardware algorithms through external memory, using the MathWorks® simplified AXI4 manager protocol. Both the writer and the reader are managers, sending read and write requests to memory through the block. The external memory is unmanaged (no logical buffers, no circular buffer). To ensure the integrity of the data, the reader and writer coordinate timing on accesses.
This block is equivalent to a Memory Channel block with the
Channel type parameter set to AXI4 Random
Access
connected to a Memory Controller block.
For more information, see Simplified AXI4 Master Interface.
Ports
Input
wrData
— Writer data bus signal
scalar | vector | matrix
This signal contains the data to the memory.
Data Types: single
| double
| int8
| int16
| int32
| int64
| uint8
| uint16
| uint32
| uint64
| Boolean
| fixed point
rdCtrlIn
— Reader input control signal
bus
This port accepts a control bus from a data consumer block, signaling that the consumer block is ready to accept read data. This input is a read-request from the reader. To create the control bust, use the SoC Bus Creator block.
Data Types: ReadControlM2SBusObj
wrCtrlIn
— Writer input control signal
bus
This port accepts a control bus from a data producer block, signaling that the producer block is ready to send data. This input is a write-request from the writer. To create the control bus, use the SoC Bus Creator block.
Data Types: WriteControlM2SBusObj
Output
rdData
— Output data signal to data consumer
scalar | vector | matrix
This signal contains the data read from the memory.
Data Types: single
| double
| int8
| int16
| int32
| int64
| uint8
| uint16
| uint32
| uint64
| Boolean
| fixed point
rdCtrlOut
— Reader control signal from memory channel to data consumer
bus
This bus represents the protocol bus from the memory channel to the data consumer. To separate the signal from the bus, use the SoC Bus Selector block.
Data Types: ReadControlS2MBusObj
wrCtrlOut
— Writer control signal from memory channel to data producer
bus
This bus represents the protocol bus from the memory channel to the data producer. To separate the signal from the bus, use the SoC Bus Selector block.
Data Types: WriteControlS2MBusObj
Parameters
Memory simulation
— Set simulation timing accuracy
Burst accurate
(default) | Protocol accurate
Memory simulation provides two levels of timing resolution. Select one of these options:
Burst accurate — Simulates memory contention and high-resolution timing.
Protocol accurate — Simulates AXI4 protocol hand-shaking sequencing and low-resolution timing.
Main
Memory selection
— Choose between memory regions
PS memory
(default) | PL memory
Select between processing subsystem (PS) or programming logic (PL) memory.
If the selected board supports only a PL memory, then the default value is
PL memory
.If the selected board supports only PS memory or only PL memory, then this parameter is read-only.
If the selected board is not a supported SoC board, then this parameter is not visible.
Region size (bytes)
— Size of the allocated memory region, in bytes
calculated
This property is read-only.
The size of the region in bytes. This value is equal to the buffer size.
Buffer size (bytes)
— Size of buffer, in bytes
4096 (default) | scalar
Specify the size of the memory buffer in bytes.
Signal Attributes
Write data signalDimensions
— Dimensions of input data signal
scalar | array
wrData can be a multidimensional array. Specify the dimension for the array as a whole number.
Example: 1 — A scalar sample.
Example: [10 1] — A vector of ten scalars.
Example: [1080 1920 3] — A 1080p frame. The frame includes 1080 lines of 1920 pixels per line, and each pixel is represented by three values (for red, green, and blue).
Data type
— Data type of writer data
uint32 (default) | double | single | int8 | int16 | int32 | int64 | uint8 | uint16 | uint64 | boolean | fixed point
Specify the data type of the wrData port. For help, click the ... button and select Data Type Assistant.
Sample time
— Time interval of sampling
1 (default) | positive scalar | vector
Specify a time interval in seconds to define how often the block updates.
When you do not want the output to have a time offset, specify the
Sample time parameter as a scalar. To add a time offset to the
output, specify the Sample time parameter as a
1
-by-2
vector, where the first element is the
sampling period and the second element is the offset. For more information about
sample times in Simulink®, see Specify Sample Time.
Enable sample packing (last signal dimension as channel)
— Pack data on the last dimension of the signal
off
(default) | on
Select this parameter to enable data packing across the last dimension of the
signal. The AXI4-Random Access Memory block packs the data along the
last dimension of the signal. For example, if the channel data type is
uint32
, the dimensions are [1024 4]
. If you
select this sample packing parameter, then the memory channel generates 1024 read or
write transactions of 128 bits. If you clear this sample packing parameter, the memory
channel generates 4096 transactions of 32 bits each.
This figure shows how data is aligned for a signal with data type
fixdt10[4x3]
. When the data is packed, three 10-bit words are
concatenated and extended by 2 bits to a 32-bit word. When the data is not packed,
each 10-bit word is extended to a 16-bit word.
This figure shows how data is aligned for a signal with data type
uint8[8x3]
. When the data is packed, three 8-bit words are
concatenated and extended by 8 bits to a 32-bit word. When the data is not packed,
each 8-bit word is represented as an 8-bit sample.
The combined width of the flattened signal must not exceed 512 bits.
Output data signal matches input
— Reader and writer use the same values
on (default) | off
Select this box to use the same dimensions and data type for the reader and the writer of this channel. Clear the box to customize different dimensions and data type for the reader and writer interfaces.
Dimensions
— Dimensions of output data signal
scalar | array
rdData can be a multidimensional array. Specify the dimension for the array as a whole number.
Example: 1 — A scalar sample.
Example: [10 1] — A vector of ten scalars.
Example: [1080 1920 3] — A 1080p frame. The frame includes 1080 lines of 1920 pixels per line, and each pixel is represented by three values (for red, green, and blue).
Data type
— Data type of reader data
uint32 (default) | double | single | int8 | int16 | int32 | int64 | uint8 | uint16 | uint64 | boolean | fixed point
Specify the data type of the rdData port. For help, click the ... button and select Data Type Assistant.
Dependencies
To enable this parameter, clear the Output data signal matches input check box.
Sample time
— Time interval of sampling
1 (default) | positive scalar | vector
Specify a time interval in seconds to define how often the block updates.
When you do not want the output to have a time offset, specify the
Sample time parameter as a scalar. To add a time offset to the
output, specify the Sample time parameter as a
1
-by-2
vector, where the first element is the
sampling period and the second element is the offset. For more information about
sample times in Simulink, see Specify Sample Time.
Dependencies
To enable this parameter, clear the Output data signal matches input check box.
Enable sample packing (last signal dimension as channel)
— Pack data on last dimension of the signal
off
(default) | on
Select this parameter to enable data packing across the last dimension of the
signal. The AXI4 Random Access Memory block packs the data along the
last dimension of the signal. For example, if the channel data type is
uint32
, the dimensions are [1024 4]
. If you
select this sample packing parameter, then the memory channel generates 1024 read or
write transactions of 128 bits. If you clear this sample packing parameter, the memory
channel generates 4096 transactions of 32 bits each.
This figure shows how data is aligned for a signal with data type
fixdt10[4x3]
. When the data is packed, three 10-bit words are
concatenated and extended by 2 bits to a 32-bit word. When the data is not packed,
each 10-bit word is extended to a 16-bit word.
This figure shows how data is aligned for a signal with data type
uint8[8x3]
. When the data is packed, three 8-bit words are
concatenated and extended by 8 bits to a 32-bit word. When the data is not packed,
each 8-bit word is represented as an 8-bit sample.
The combined width of the flattened signal must not exceed 512 bits.
Dependencies
To enable this parameter, clear the Output data signal matches input check box.
Performance
View performance plots
— Display performance metrics
button
Clicking the button opens the Performance Plots for Memory Controller window. You can then select to plot bandwidth, bursts, or latencies. For more information about performance graphs, see Memory Controller Latency Plots.
Dependencies
To enable this parameter, select Burst accurate under Memory simulation.
Extended Capabilities
HDL Code Generation
Generate Verilog and VHDL code for FPGA and ASIC designs using HDL Coder™.
Fixed-Point Conversion
Design and simulate fixed-point systems using Fixed-Point Designer™.
Version History
Introduced in R2022b
