Documentation

# psnr

Peak Signal-to-Noise Ratio (PSNR)

## Description

example

peaksnr = psnr(A,ref) calculates the peak signal-to-noise ratio for the image A, with the image ref as the reference.

peaksnr = psnr(A,ref,peakval) uses peakval as the peak signal value for calculating the peak signal-to-noise ratio for image A.

[peaksnr,snr] = psnr(___) returns the simple signal-to-noise ratio, snr, in addition to the peak signal-to-noise ratio.

## Examples

collapse all

Read image and create a copy with added noise. The original image is the reference image.

A = imnoise(ref,'salt & pepper', 0.02);

Calculate the PSNR.

[peaksnr, snr] = psnr(A, ref);

fprintf('\n The Peak-SNR value is %0.4f', peaksnr);
The Peak-SNR value is 22.6437
fprintf('\n The SNR value is %0.4f \n', snr);
The SNR value is 15.5524

## Input Arguments

collapse all

Image to be analyzed, specified as a numeric array of any dimension.

Data Types: single | double | int16 | uint8 | uint16

Reference image, specified as a numeric array of the same size and data type as image A.

Data Types: single | double | int16 | uint8 | uint16

Peak signal level, specified as a nonnegative number. If not specified, the default value for peakval depends on the class of A and ref.

• If the images are of data type double or single, then psnr assumes that image data is in the range [0, 1] and the default value of peakval is 1.

• If the images are of integer data types, then the default value of peakval is the largest value allowed by the range of the class. For uint8 data, the default value of peakval is 255. For uint16 or int16, the default is 65535.

## Output Arguments

collapse all

Peak signal-to-noise ratio in decibels, returned as a scalar of type double, except if A and ref are of class single, in which case peaksnr is of class single.

Data Types: single | double

Signal-to-noise ratio in decibels, returned as a numeric scalar of type double, except if A and ref are of class single, in which case peaksnr is of type single.

Data Types: single | double

## Algorithms

The psnr function implements the following equation to calculate the Peak Signal-to-Noise Ratio (PSNR):

$PSNR=10{\mathrm{log}}_{10}\left(peakva{l}^{2}/MSE\right)$

where peakval is either specified by the user or taken from the range of the image datatype (e.g. for uint8 image it is 255). MSE is the mean square error, i.e. MSE between A and ref.
