LEFA (Lineament Extraction Fracture Analysis)

Version 1.2.0.2 (13,2 MB) von Sergey Shevyrev
Analysis of fracture pattern of remote sensing images
0.0
(0)
519 Downloads
Aktualisiert 6. Sep 2018

Lizenz anzeigen

Project LEFA (http://lefa.geologov.net) is GUI Matlab script package created
for satellite image decomposition for Earth sciences implications. Fracture
analysis is often being used for geological mapping, detecting natural hazards
and prospecting of mineral resources. Achievements in computer image
processing and digital mapping made possible human independent feature
recognition.
LEFA contains free of charge set of Matlab scripts, which allows to:
-Extract lineament features on satellite image (Landsat 7 and 8, SRTM and
some others are supported);
-Compute feature spatial distribution parameters (density and Minkowski
Dimension);
-Create Rose diagram plot of lineaments direction;
- Export features into ESRI shape format to continue work in GIS software.
LEFA uses single window interface for the whole cycle of image processing.

Zitieren als

Sergey Shevyrev (2024). LEFA (Lineament Extraction Fracture Analysis) (https://www.mathworks.com/matlabcentral/fileexchange/67373-lefa-lineament-extraction-fracture-analysis), MATLAB Central File Exchange. Abgerufen.

Kompatibilität der MATLAB-Version
Erstellt mit R2013b
Kompatibel mit allen Versionen
Plattform-Kompatibilität
Windows macOS Linux
Quellenangaben

Inspiriert von: boxcount

Community Treasure Hunt

Find the treasures in MATLAB Central and discover how the community can help you!

Start Hunting!

lefa_v1_202

lefa_v1_202/m

Version Veröffentlicht Versionshinweise
1.2.0.2

Fixed bugs with shape file output and some minor issues resolved.
1.2.0.1

1.03 Update fixed the bug with line density counting upon downsampled image.
1.2.0.0

GeoTiff downsampling function has been added.
1.02 GeoTiff downsampling function has been added.
1.01 Added some UI features.
1.00 Basic and buggy initial release.
1.1.0.0

Fixed minor bugs, handled some exeptions
1.0.0.0

Minor issues are fixed
Description has been edited
