WLAN Toolbox™ provides functions that let you measure transmitter performance characteristics. The examples featured here demonstrate transmitter modeling and performance analysis. Communications Toolbox™ and DSP System Toolbox™ System objects provide additional quantitative tools for measuring system performance, and graphical utilities for visualizing waveforms.
|WLAN Waveform Generator||Create, impair, visualize, and export WLAN waveforms|
|Waveform From Wireless Waveform Generator App||Wireless waveform source exported to Simulink|
802.11 OFDM Beacon Frame Generation and Transmission with Test and Measurement Equipment (Instrument Control Toolbox)
This example shows how to generate packets containing MAC beacon frames suitable for baseband simulation or over-the-air transmission using WLAN Toolbox™, Instrument Control Toolbox™ and Keysight Technologies® RF signal generator.
This example shows how to configure and use the block that is generated using the Export to Simulink capability that is available in the Wireless Waveform Generator app.
