Resample time-domain data by decimation or interpolation (requires Signal Processing Toolbox software)
resample(data,P,Q)
resample(data,P,Q,order)
resample(data,P,Q)
resamples data such
that the data is interpolated by a factor P
and
then decimated by a factor Q
. resample(z,1,Q)
results
in decimation by a factor Q
.
resample(data,P,Q,order)
filters the data
by applying a filter of specified order
before
interpolation and decimation.
data
Name of time-domain iddata
object. Can be
input-output or time-series data.
Data must be sampled at equal time intervals.
P
, Q
Integers that specify the resampling factor, such that the new
sample time is Q/P
times the original one.
(Q/P)>1
results in decimation and (Q/P)<1
results
in interpolation.
order
Order of the filters applied before interpolation and decimation.
Default: 10
If you have installed the Signal Processing Toolbox™ software, resample
calls
the Signal Processing Toolbox resample
function.
The algorithm takes into account the intersample characteristics of
the input signal, as described by data.InterSample
.
