Quellen und Sinks

Eingangs- und Ausgangssignale und -Sequenzen und Datei-E/A-Formate

Generieren Sie Signal-Quellendaten und Rauschen, um Kommunikationsverbindungen zu simulieren. Visualisieren und analysieren Sie die Leistung Ihrer Kommunikationssystem-Simulation.

Die unterstützten Dateiformate zur Verarbeitung erfasster Signale umfassen binäre Basisband-Signalformate und NI™ TDMS-Formate (Technical Data Management Solution). Sie können Daten in Tabellen oder Timetables übertragen, indem Sie TDMS-Dateien einzeln oder Sammlungen von TDMS-Dateien simultan auslesen.

Apps

Wireless Waveform Generator

Create, impair, visualize, and export modulated waveforms

Funktionen

alle erweitern

Quellen

`randi`	Uniformly distributed random integers
`randerr`	Generate bit error patterns
`randsrc`	Generate random matrix using prescribed alphabet
`commsrc.combinedjitter`	Construct combined jitter generator object
`commsrc.pattern`	Construct pattern generator object
`zadoffChuSeq`	Generate root Zadoff-Chu sequence
`mask2shift`	Convert mask vector to shift for linear shift register
`shift2mask`	Convert shift to mask vector for linear shift register
`wgn`	Generate white Gaussian noise samples

Sinks

`biterr`	Compute number of bit errors and bit error rate (BER)
`eyediagram`	Generate eye diagram
`scatterplot`	Display input signal in IQ-plane
`symerr`	Compute number of symbol errors and symbol error rate

TDMS-Datei

`tdmsread`	Read data from TDMS file (Seit R2022a)
`tdmswrite`	Write data to TDMS file (Seit R2022b)
`tdmsinfo`	Information about TDMS file (Seit R2022a)
`tdmsreadprop`	Read properties as single row table from TDMS file (Seit R2022a)
`tdmswriteprop`	Write properties to TDMS file (Seit R2022b)

Objekte

alle erweitern

Quellen

`comm.BarkerCode`	Generate bipolar Barker code
`comm.GoldSequence`	Generate Gold sequence from set of sequences
`comm.HadamardCode`	Generate Hadamard code
`comm.KasamiSequence`	Generate Kasami sequence
`comm.OVSFCode`	Generate OVSF code
`comm.PNSequence`	Generate a pseudonoise (PN) sequence
`comm.RBDSWaveformGenerator`	Generate RDS/RBDS waveform
`comm.WalshCode`	Generate bipolar Walsh code

Sinks

comm.ConstellationDiagram Display and analyze input signals in IQ-plane

Datei-E/A

`comm.BasebandFileReader`	Read baseband signal from file
`comm.BasebandFileWriter`	Write baseband signal to file
`tdmsDatastore`	Datastore for collection of TDMS files (Seit R2022a)

Blöcke

alle erweitern

Quellen

Barker Code Generator	Generate bipolar Barker Code
Bernoulli Binary Generator	Generate Bernoulli-distributed random binary numbers
Gold Sequence Generator	Generate Gold sequence from set of sequences
Hadamard Code Generator	Generate Hadamard code from orthogonal set of codes
Kasami Sequence Generator	Generate Kasami sequence from set of Kasami sequences
OVSF Code Generator	Generate OVSF code
PN Sequence Generator	Generate pseudonoise sequence
Poisson Integer Generator	Generate Poisson-distributed random integers
Random Integer Generator	Generate integers randomly distributed in specified range
Walsh Code Generator	Generate Walsh code from orthogonal set of codes

Sinks

Constellation Diagram	Display and analyze input signals in IQ-plane
Eye Diagram	Display eye diagram of time-domain signal (Seit R2023b)

Datei-E/A

Baseband File Writer	Write baseband signals to file
Baseband File Reader	Read baseband signals from file

Themen

Create Waveforms Using Wireless Waveform Generator App
Create, impair, visualize, and export modulated waveforms.
Signal Terminology
Learn about terms related to matrices, vectors, and scalars, as well as frame-based and sample-based processing.
Sinks
Use sinks and display devices to analyze communications system performance.
Random Noise Generators
Spreading Sequences
Compare spreading sequences for single and multiuser scenarios in single path and multipath environments.
Export Data to MATLAB
Send simulation results to the MATLAB workspace and use MATLAB to analyze the data.
