numericalPropagator
Description
adds a numerical orbit propagator to scenario using options specified by one or more
name-value arguments. If the scenario already contains a numerical orbit propagator, it
updates the currently used options specified by the name-value arguments. The options
corresponding to the unspecified name-value arguments remain unchanged. When
options
= numericalPropagator(___,Name=Value
)AutoSimulate
of scenario
is
false
, you can specify the optional name-value arguments only if
SimulationStatus
is set to NotStarted
.
Input Arguments
scenario
— Satellite scenario
satelliteScenario
object
Satellite scenario, specified as a satelliteScenario
object.
Name-Value Arguments
Specify optional pairs of arguments as
Name1=Value1,...,NameN=ValueN
, where Name
is
the argument name and Value
is the corresponding value.
Name-value arguments must appear after other arguments, but the order of the
pairs does not matter.
Example: ODESolver = 'ode78'
sets the ODE solver to
'ode78'
.
ODESolver
— ODE solver used by propagator
'ode23'
| 'ode78'
| 'ode89'
| 'ode113'
| 'ode15s'
| 'ode23s'
| 'ode23t'
| or 'ode23tb'
Ordinary differential equation (ODE) solver used by the numerical orbit
propagator, specified as 'ode45'
, 'ode23'
,
'ode78'
, 'ode89'
, 'ode113'
,
'ode15s'
,
'ode23s'
,'ode23t'
, or
'ode23tb'
.
Default Value
The default value is the current value of ODESolver
of
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
'ode45'
otherwise.
ODESet
— ODE solver options
current value of ODESet
in
NumericalPropagatorOptions
if property is nonempty, and structure
returned by odeset(RelTol=1e-8,AbsTol=1e-8)
otherwise
ODE solver options, specified as the structure returned by odeset
(RelTol=1e-8, AbsTol=1e-8)
.
GravitationalPotentialModel
— Gravitational potential model of Earth
'point-mass'
| 'oblate-ellipsoid'
Gravitational potential model of Earth, specified
'spherical-harmonics'
, 'point-mass'
, or
'oblate-ellipsoid'
.
Default Value
The default value is the current value of
GravitationalPotentialModel
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
'spherical-harmonics'
otherwise.
SphericalHarmonicModel
— Spherical harmonic model of gravitational potential of Earth
'EGM96'
| 'EIGENGL04C'
Spherical harmonic model of gravitational potential of Earth, specified as
'EGM2008'
, 'EGM96'
, or
'EIGENGL04C'
.
Default Value
The default value is the current value of
SphericalHarmonicModel
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
'EGM2008'
otherwise.
Dependencies
To use this input, GravitationalPotentialModel
must be set
to 'spherical-harmonics'
.
SphericalHarmonicDegree
— Spherical harmonic degree of gravitational potential of Earth
scalar
Spherical harmonic degree of gravitational potential of Earth, specified as a scalar.
Default Value
The default value is the current value of
SphericalHarmonicDegree
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and 120
otherwise.
Dependencies
To use this input, GravitationalPotentialModel
must be set
to 'spherical-harmonics'
.
Data Types: double
IncludeAtmosDrag
— Option to indicate whether propagator must account for atmospheric drag
false
or 0
| true
or 1
Option to indicate whether the propagator must account for atmospheric drag,
specified as false
(0
) or
true
(1
). When set to true
,
the propagator calculates atmospheric drag based on the NRLMSISE-00 model for
atmospheric density.
Default Value
The default value is the current value of IncludeAtmosDrag
in
NumericalPropagatorOptions
property of
scenario
.
UseSpaceWeatherDataFile
— Option to use MAT file containing consolidated space weather data file in atmospheric density calculation
false
or 0
| true
or 1
Option to use MAT file containing consolidated space weather data file in
atmospheric density calculation, specified as false
(0
) or true
(1
). See
aeroReadSpaceWeatherData
for more information on how to generate this
MAT file.
Default Value
The default value is the current value of
UseSpaceWeatherDataFile
in
NumericalPropagatorOptions
property of
scenario
.
Dependencies
To use this inputGravitationalPotentialModel
is set to
'spherical-harmonics'
.
SpaceWeatherDataFile
— MAT file containing consolidated space weather data file in atmospheric density calculation
character vector | string
MAT file containing consolidated space weather data file in atmospheric density calculation, specified as a character vector or string.
Default Value
The default value is the current value of
SpaceWeatherDataFile
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
"aeroSpaceWeatherData.mat"
otherwise.
Dependencies
To use this input, IncludeAtmosDrag
and
UseSpaceWeatherDataFile
must be set to
true
.
F107ExtrapMethod
— Method used for extrapolating F10.7 solar flux for times outside range of space weather data file
'constant'
| 'least-squares-fit'
Method used for extrapolating F10.7 solar flux for times outside the range of the space weather data file, specified as one of these values:
'none-clip'
— F10.7 value is set to the nearest data point available in the space weather data file.'constant'
— F10.7 value is set to a constant value specified by theF107ExtrapValue
name-value argument.'least-squares-fit'
— F10.7 value is approximated using a least-squares fit of the space weather data from October 1, 1957, to December 1, 2040, using the trigonometric function a+bcos(ct + dsin(et)).
Default Value
The default value is the current value of F107ExtrapMethod
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
'none-clip'
otherwise.
Dependencies
To use this inputIncludeAtmosDrag
and
UseSpaceWeatherDataFile
are set to
true
.
F107ExtrapValue
— Extrapolation value for F10.7 solar flux
nonnegative scalar
Extrapolation value for the F10.7 solar flux, specified as a nonnegative scalar.
Default Value
The default value is the current value of F107ExtrapValue
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and 150
otherwise.
Dependencies
To use this input, IncludeAtmosDrag
,
UseSpaceWeatherDataFile
, and
F107ExtrapMethod
must be set to
'constant'
.
F107Average
— Centered 81-day average value of F10.7 solar flux
nonnegative scalar
Centered 81-day average value of the F10.7 solar flux, specified as a nonnegative scalar.
Default Value
The default value is the current value of F107Average
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and 150
otherwise.
Dependencies
To use this inputIncludeAtmosDrag
and
UseSpaceWeatherDataFile
are set to
false
.
F107Daily
— Daily value of F10.7 solar flux
current value of F107Daily
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and 150
otherwise (default) | nonnegative scalar
Daily value of F10.7 solar flux from the previous day, specified as a nonnegative scalar.
Default Value
The default value is the current value of F107Daily
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and 150
otherwise.
Dependencies
To use this input, UseSpaceWeatherDataFile
must be set to
false
.
MagneticIndexExtrapMethod
— Method used for extrapolating magnetic index for times outside range of space weather data file
'constant'
| 'least-squares-fit'
Method used for extrapolating magnetic index for times outside the range of the space weather data file, specified as one of these values:
'none-clip'
— Magnetic index is set to the nearest data point available in the space weather data file.'constant'
— Magnetic index is set to a constant value specified byMagneticIndexExtrapValue
.'igrf'
— Magnetic index is calculated using International Geomagnetic Reference Field. Because this model is defined for times between January 1, 1900, 12:00 AM UTC and January 1, 2025, 12:00 AM UTC, the predictions for times outside this range are clipped to values at these time limits.
Default Values
The default value is the current value of
SpaceWeatherDataFile
in F107ExtrapMethod
property of scenario
if property is nonempty, and
'none-clip'
otherwise.
Dependencies
To use this input IncludeAtmosDrag
and
UseSpaceWeatherDataFile
must be set to
false
.
MagneticIndexExtrapValue
— Extrapolation value for magnetic index
nonnegative scalar
Extrapolation value for the magnetic index, specified as a nonnegative scalar.
Default Value
The default value is the current value of
MagneticIndexExtrapValue
in F107ExtrapMethod
property of scenario
if property is nonempty, and
4
otherwise.
Dependencies
To use this input:
IncludeAtmosDrag
andUseSpaceWeatherDataFile
must be set totrue
.MagneticIndexExtrapMethod
must be set to'constant'
.
MagneticIndex
— Magnetic index information
seven-element nonnegative row vector
Magnetic index information, specified as a seven-element row vector. This value consists of magnetic index representing a daily value (AP), three hour AP for a reference time, three hour AP for three hours before the reference time, three hour AP for six hours before the reference time, three hour AP for nine hours before the reference time, average of eight three hour AP indices from 12 to 33 hours prior to the reference time, and average of eight three hour AP indices from 36 to 57 hours prior to the reference time. This vector is constant for the entire scenario.
Default Value
The default value is the current value of MagneticIndex
in
F107ExtrapMethod
property of scenario
if
property is nonempty, and [4 4 4 4 4 4 4]
otherwise.
Dependencies
To use this input:
IncludeAtmosDrag
must be set totrue
.UseSpaceWeatherDataFile
must be set tofalse
.
IncludeAnomalousOxygen
— Option to specify whether anomalous oxygen must be included in atmospheric mass density calculation
false
or 0
| true
or 1
Option to specify whether anomalous oxygen must be included in the atmospheric
mass density calculation, specified as false
(0
)
or true
(1
).
Default Value
The default value is the current value of
IncludeAnomalousOxygen
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and true
or 1
otherwise.
Dependencies
To use this input, IncludeAtmosDrag
must be set to
true
.
AtmosFlags
— Option to activate or deactivate particular variations in atmospheric mass density calculation
vector of 23 double elements
Option to activate or deactivate particular variations in atmospheric mass density calculation, specified as a vector of 23 double elements. The elements are defined in the order shown in the table:
AtmosFlags
elements
Element | Value |
---|---|
1 | F10.7 effect on mean |
2 | Independent of time |
3 | Symmetrical annual |
4 | Symmetrical semiannual |
5 | Asymmetrical annual |
6 | Asymmetrical semiannual |
7 | Diurnal |
8 | Semidiurnal |
9 | Daily AP. If you set this value to -1, the atmospheric mass density computation uses the entire magnetic index information that includes the three-hour averages, as opposed to just the daily value. |
10 | All UT seconds, longitudinal effects |
11 | Longitudinal |
12 | UT seconds and mixed UT seconds, longitudinal |
13 | Mixed AP, UT seconds, longitudinal |
14 | Terdiurnal |
15 | Departures from diffusive equilibrium |
16 | All exospheric temperature variations |
17 | All variations from 120,000 meter temperature (TLB) |
18 | All lower thermosphere (TN1) temperature variations |
19 | All 120,000 meter gradient (S) variations |
20 | All upper stratosphere (TN2) temperature variations |
21 | All variations from 120,000 meter values (ZLB) |
22 | All lower mesosphere temperature (TN3) variations |
23 | Turbopause scale height variations |
With the exception of element 9 (daily AP), the elements are specified as 0 or 1. Element 9 is specified as -1, 0 or 1.
Default Value
The default value is the current value of AtmosFlags
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, or
ones(1,23)
otherwise.
Dependencies
To use this input, IncludeAtmosDrag
must be set to
true
.
IncludeThirdBodyGravity
— Option to specify whether third body gravity should be included
false
or 0
| true
or 1
Option to specify whether third body gravity should be included, specified as
false
(0
) or true
(1
).The third body gravity sources are assumed to be point
masses.
Default Value
The default value is the current value of
IncludeThirdBodyGravity
in
NumericalPropagatorOptions
property of
scenario
.
ThirdBodyGravitySource
— Third body gravity source
'sun'
| 'moon'
| 'mercury'
| 'venus'
| 'mars'
| 'jupiter'
| 'saturn'
| 'uranus'
| 'neptune'
| 'pluto'
Third body gravity source, specified as one of 'sun'
,
'moon'
, 'mercury'
, 'venus'
,
'mars'
, 'jupiter'
,
'saturn'
, 'uranus'
,
'neptune'
, or 'pluto'
.
Default Values
The default value is the current value of
ThirdBodyGravitySource
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and ["Sun"
"Moon"]
otherwise.
Dependencies
To use this input, IncludeThirdBodyGravity
must be set to
true
.
IncludeSRP
— Option to indicate whether solar radiation pressure should be included
false
or 0
| true
or 1
Option to indicate whether solar radiation pressure should be included, specified
as false
(0
) or true
(1
).
Default Value
The default value is the current value of IncludeSRP
in
NumericalPropagatorOptions
property of
scenario
.
SolarFluxPressure
— Solar flux pressure acting at 1 Astronomical Unit (AU) from Sun
nonnegative scalar
Solar flux pressure acting at 1 Astronomical Unit (AU) from Sun, specified as a nonnegative scalar in W*s/m3.
Default Value
The default value is the current value of SolarFluxPressure
in NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
4.5344321e-6
otherwise.
Data Types: double
EclipseModel
— Eclipse model used in solar radiation pressure computation
'cylindrical'
Eclipse model used in the solar radiation pressure computation, specified as one
of 'dual-cone'
or 'cylindrical'
.
Default Values
The default value is the current value of EclipseModel
in
NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
'dual-cone'
otherwise.
Dependencies
To use this input, IncludeSRP
must be set to
true
Data Types: string
IncludeLunarEclipse
— Option to indicate whether lunar occultation must be included in solar radiation pressure calculation
true
or 1
Option to indicate whether lunar occultation must be included in solar radiation
pressure calculation, specified as false
(0
) or
true
(1
).
Default Values
The default value is the current value of IncludeLunarEclipse
in NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
false
otherwise.
Dependencies
To use this input, IncludeSRP
must be set to
true
Data Types: logical
PlanetaryEphemerisModel
— Celestial body ephemeris model used in the computation of third body gravity and solar radiation pressure
'de421'
| 'de423'
| 'de430'
| 'de432t'
Celestial body ephemeris model used in the computation of third body gravity and solar radiation pressure, specified as one of:
'de405'
— Released in 1998. This ephemerides takes into account the Julian date range 2305424.50 (December 9, 1599) to 2525008.50 (February 20, 2201).'de421'
— Released in 2008. This ephemerides takes into account the Julian date range 2414992.5 (December 4, 1899) to 2469808.5 (January 2, 2050).'de423'
— Released in 2010. This ephemerides takes into account the Julian date range 2378480.5 (December 16, 1799) to 2524624.5 (February 1, 2200).'de430'
— Released in 2013. This ephemerides takes into account the Julian date range 2287184.5 (December 21, 1549) to 2688976.5 (January 25, 2650).'de432t'
— Released in April 2014. This ephemerides takes into account the Julian date range 2287184.5, (December 21, 1549 ) to 2688976.5, (January 25, 2650).
Default Values
The default value is the current value of EphemerisModel
of
the NumericalPropagatorOptions
property of
scenario
if property is nonempty, and
'de405'
otherwise.
Dependencies
To use this input, IncludeSRP
and
IncludeThirdBodyGravity
must be set to
true
.
Data Types: string
Output Arguments
options
— Currently used options for the numerical orbit propagator
NumericalPropagatorOptions
object
Currently used options for the numerical orbit propagator, returned as a scalar
NumericalPropagatorOptions
object.
Version History
Introduced in R2024a
See Also
Objects
Functions
MATLAB-Befehl
Sie haben auf einen Link geklickt, der diesem MATLAB-Befehl entspricht:
Führen Sie den Befehl durch Eingabe in das MATLAB-Befehlsfenster aus. Webbrowser unterstützen keine MATLAB-Befehle.
Select a Web Site
Choose a web site to get translated content where available and see local events and offers. Based on your location, we recommend that you select: .
You can also select a web site from the following list:
How to Get Best Site Performance
Select the China site (in Chinese or English) for best site performance. Other MathWorks country sites are not optimized for visits from your location.
Americas
- América Latina (Español)
- Canada (English)
- United States (English)
Europe
- Belgium (English)
- Denmark (English)
- Deutschland (Deutsch)
- España (Español)
- Finland (English)
- France (Français)
- Ireland (English)
- Italia (Italiano)
- Luxembourg (English)
- Netherlands (English)
- Norway (English)
- Österreich (Deutsch)
- Portugal (English)
- Sweden (English)
- Switzerland
- United Kingdom (English)
