Three phase STATCOM using D-Q control

Version 1.0.0 (73,6 KB) von Rajesh Farswan
Three phase VSI STATCOM supplying reactive power to R-L load
5.0
(1)
1,6K Downloads
Aktualisiert 11. Sep 2019

Lizenz anzeigen

Three phase STATCOM inverter is driven using Sine PWM. The sine references are generated using a PLL and Harmonic oscillator. The closed loop control is implemented in synchronous reference frame.
Reactive power demand of the load is supplied by STATCOM in such a way that only active power is taken from the grid source.

Zitieren als

Rajesh Farswan (2024). Three phase STATCOM using D-Q control (https://www.mathworks.com/matlabcentral/fileexchange/72709-three-phase-statcom-using-d-q-control), MATLAB Central File Exchange. Abgerufen.
