Apply function to nonzero sparse matrix elements


f = spfun(fun,S)


The spfun function selectively applies a function to only the nonzero elements of a sparse matrix S, preserving the sparsity pattern of the original matrix (except for underflow or if fun returns zero for some nonzero elements of S).

f = spfun(fun,S) evaluates fun(S) on the elements of S that are nonzero. fun is a function handle.

Parameterizing Functions explains how to provide additional parameters to the function fun, if necessary.


Given the 4-by-4 sparse diagonal matrix

S = spdiags([1:4]',0,4,4)

S =
   (1,1)        1
   (2,2)        2
   (3,3)        3
   (4,4)        4

Because fun returns nonzero values for all nonzero element of S, f = spfun(@exp,S) has the same sparsity pattern as S.

f =
   (1,1)       2.7183
   (2,2)       7.3891
   (3,3)      20.0855
   (4,4)      54.5982

whereas exp(S) has 1s where S has 0s.


ans =
    2.7183    1.0000    1.0000    1.0000
    1.0000    7.3891    1.0000    1.0000
    1.0000    1.0000   20.0855    1.0000
    1.0000    1.0000    1.0000   54.5982


Functions that operate element-by-element, like those in the elfun directory, are the most appropriate functions to use with spfun.

Extended Capabilities

C/C++ Code Generation
Generate C and C++ code using MATLAB® Coder™.

Introduced before R2006a
