aPC Matlab Toolbox: Data-driven Arbitrary Polynomial Chaos

Data-driven Arbitrary Polynomial Chaos Expansion for Machine Learning, Uncertainty quantification and Global sensitivity analysis
Aktualisiert 1. Dez 2023

Lizenz anzeigen

Polynomial chaos expansion (PCE) introduced by Norbert Wiener in 1938. PCE can be seen, intuitively, as a mathematically optimal way to construct and obtain a model response surface in the form of a high-dimensional polynomial in uncertain model parameters. Recently the polynomial chaos expansion received a generalization towards the arbitrary polynomial chaos expansion (aPC: Oladyshkin S. and Nowak W., 2012), which is a so-called data-driven generalization of the PCE. Like all polynomial chaos expansion techniques, aPC approximates the dependence of simulation model output on model parameters by expansion in an orthogonal polynomial basis. The aPC generalizes chaos expansion techniques towards arbitrary distributions with arbitrary probability measures, which can be either discrete, continuous, or discretized continuous and can be specified either analytically (as probability density/cumulative distribution functions), numerically as histogram or as raw data sets. The aPC at finite expansion order only demands the existence of a finite number of moments and does not require the complete knowledge or even existence of a probability density function. This avoids the necessity to assign parametric probability distributions that are not sufficiently supported by limited available data. Alternatively, it allows modellers to choose freely of technical constraints the shapes of their statistical assumptions. Investigations indicate that the aPC shows an exponential convergence rate and converges faster than classical polynomial chaos expansion techniques. The aPC Matlab Toolbox have been developed in the year 2010 for scientific purpose and now it is available for the Matlab community (see details in Readme file).
Sergey Oladyshkin
Stuttgart Research Centre for Simulation Technology,
Department of Stochastic Simulation and Safety Research for Hydrosystems,
Institute for Modelling Hydraulic and Environmental Systems,
University of Stuttgart, Pfaffenwaldring 5a, 70569 Stuttgart
E-mail: Sergey.Oladyshkin@iws.uni-stuttgart.de
Phone: +49-711-685-60116
Fax: +49-711-685-51073
Website: http://www.iws.uni-stuttgart.de

Zitieren als

Sergey Oladyshkin (2024). aPC Matlab Toolbox: Data-driven Arbitrary Polynomial Chaos (https://www.mathworks.com/matlabcentral/fileexchange/72014-apc-matlab-toolbox-data-driven-arbitrary-polynomial-chaos), MATLAB Central File Exchange. Abgerufen .

Oladyshkin, S., and W. Nowak. “Data-Driven Uncertainty Quantification Using the Arbitrary Polynomial Chaos Expansion.” Reliability Engineering & System Safety, vol. 106, Elsevier BV, Oct. 2012, pp. 179–90, doi:10.1016/j.ress.2012.05.002.

Mehrere Stile anzeigen

Oladyshkin, Sergey, and Wolfgang Nowak. “Incomplete Statistical Information Limits the Utility of High-Order Polynomial Chaos Expansions.” Reliability Engineering & System Safety, vol. 169, Elsevier BV, Jan. 2018, pp. 137–48, doi:10.1016/j.ress.2017.08.010.

Mehrere Stile anzeigen

Oladyshkin S., de Barros F. P. J. and Nowak W. Global sensitivity analysis: a flexible and efficient framework with an example from stochastic hydrogeology. Advances in Water Resources 37, 10-2, 2012, doi: 10.1016/j.advwatres.2011.11.001.

Kompatibilität der MATLAB-Version
Erstellt mit R2019a
Kompatibel mit allen Versionen
Windows macOS Linux

Community Treasure Hunt

Find the treasures in MATLAB Central and discover how the community can help you!

Start Hunting!
Version Veröffentlicht Versionshinweise

Sparse representation and GP properties


Multivariate Polynomial Degrees


FT Update


PCM Update




Object Oriented Version


Object Oriented Set Up


Object Oriented Version






New option: aPC based global sensitivity analysis


line 33 in MainRun_aPC.m
