Pixel Processing

Control block for Pixel Processing Subsystem

Since R2024a

    Description

    The Pixel Processing block serves as a control block for the Pixel Processing Subsystem block. The Pixel Processing Subsystem block iterates over a 3-dimensional input matrix. At each iteration step, the subsystem processes a 1-by-1-by-n subset of the input matrix, where n is the size of the third dimension of the input matrix. The subsystem outputs a 2-dimensional matrix with the same first two dimensions as the input matrix.

    Extended Capabilities

    C/C++ Code Generation
    Generate C and C++ code using Simulink® Coder™.

    Version History

    Introduced in R2024a
