Video Stream Connector

Connect two IPs with video streaming interfaces

  • Library:
  • SoC Blockset / Hardware Logic Connectivity

Description

The Stream Connector block connects two IPs with video streaming interfaces. Use this block in the FPGA model of an SoC application to connect two IPs.

Ports

Input

expand all

Input video data from the data source. Specify this value as a scalar.

Data Types: single | double | int8 | int16 | int32 | uint8 | uint16 | uint32 | fixed point

Control signals accompanying the pixel stream, specified as a pixelcontrol bus containing five signals. The signals describe the validity of the pixel and its location in the frame. For additional information about the pixelcontrol bus type, see AXI4-Stream Video Interface.

Data Types: pixelcontrol

Control signal that indicates if the block can send video data to downstream interface. When this value is (true), the downstream block is ready to receive data.

Output

expand all

Output video data to the downstream destination IP.

Data Types: single | double | int8 | int16 | int32 | uint8 | uint16 | uint32 | fixed point

Control signals accompanying the output video data, specified as a pixelcontrol bus containing five signals. The signals describe the validity of the pixel and its location in the frame.

Data Types: pixelcontrol

Control signal that indicates that the block can receive stream data from upstream interface.

Data Types: Boolean

Extended Capabilities

Fixed-Point Conversion
Design and simulate fixed-point systems using Fixed-Point Designer™.

Introduced in R2019a
